Introduction


In this competition we'll try to predict the price of houses at Ames, Iowa.
With 80 explanatory variables describing a lot about the house.
So at first we'll try to find out which variables are probably helpful to predict the price only with EDA.
After that, we'll do some feature engineering to get the most of our dataset.
To build our model, we'll try some familiar algorithms like SGD, Linear Regression, Lasso, Ridge and Gradient Boosting Regression, and try to play with their hyper-parameters. We'll use also feature selection algorithm based on sklearn (RFE).

Import and Install Necessary Libraries

Update plotly version and install new package sweetviz to visualize datasets.

In [2]:
!pip install --upgrade plotly
!pip install sweetviz
!pip install -U scikit-learn
Collecting plotly
  Downloading https://files.pythonhosted.org/packages/1f/f6/bd3c17c8003b6641df1228e80e1acac97ed8402635e46c2571f8e1ef63af/plotly-4.14.3-py2.py3-none-any.whl (13.2MB)
     |████████████████████████████████| 13.2MB 323kB/s
Requirement already satisfied, skipping upgrade: six in /usr/local/lib/python3.6/dist-packages (from plotly) (1.15.0)
Requirement already satisfied, skipping upgrade: retrying>=1.3.3 in /usr/local/lib/python3.6/dist-packages (from plotly) (1.3.3)
Installing collected packages: plotly
  Found existing installation: plotly 4.4.1
    Uninstalling plotly-4.4.1:
      Successfully uninstalled plotly-4.4.1
Successfully installed plotly-4.14.3
Collecting sweetviz
  Downloading https://files.pythonhosted.org/packages/7c/30/686ea12dd291220340ad7b84c725f2f21b9ff3144d1f6cd430f01c54a898/sweetviz-2.0.6-py3-none-any.whl (15.1MB)
     |████████████████████████████████| 15.1MB 340kB/s
Requirement already satisfied: jinja2>=2.11.1 in /usr/local/lib/python3.6/dist-packages (from sweetviz) (2.11.3)
Requirement already satisfied: importlib-resources>=1.2.0 in /usr/local/lib/python3.6/dist-packages (from sweetviz) (5.1.0)
Requirement already satisfied: matplotlib>=3.1.3 in /usr/local/lib/python3.6/dist-packages (from sweetviz) (3.2.2)
Requirement already satisfied: numpy>=1.16.0 in /usr/local/lib/python3.6/dist-packages (from sweetviz) (1.19.5)
Requirement already satisfied: scipy>=1.3.2 in /usr/local/lib/python3.6/dist-packages (from sweetviz) (1.4.1)
Collecting tqdm>=4.43.0
  Downloading https://files.pythonhosted.org/packages/b3/db/dcda019790a8d989b8b0e7290f1c651a0aaef10bbe6af00032155e04858d/tqdm-4.56.2-py2.py3-none-any.whl (72kB)
     |████████████████████████████████| 81kB 8.9MB/s
Requirement already satisfied: pandas!=1.0.0,!=1.0.1,!=1.0.2,>=0.25.3 in /usr/local/lib/python3.6/dist-packages (from sweetviz) (1.1.5)
Requirement already satisfied: MarkupSafe>=0.23 in /usr/local/lib/python3.6/dist-packages (from jinja2>=2.11.1->sweetviz) (1.1.1)
Requirement already satisfied: zipp>=0.4; python_version < "3.8" in /usr/local/lib/python3.6/dist-packages (from importlib-resources>=1.2.0->sweetviz) (3.4.0)
Requirement already satisfied: kiwisolver>=1.0.1 in /usr/local/lib/python3.6/dist-packages (from matplotlib>=3.1.3->sweetviz) (1.3.1)
Requirement already satisfied: cycler>=0.10 in /usr/local/lib/python3.6/dist-packages (from matplotlib>=3.1.3->sweetviz) (0.10.0)
Requirement already satisfied: pyparsing!=2.0.4,!=2.1.2,!=2.1.6,>=2.0.1 in /usr/local/lib/python3.6/dist-packages (from matplotlib>=3.1.3->sweetviz) (2.4.7)
Requirement already satisfied: python-dateutil>=2.1 in /usr/local/lib/python3.6/dist-packages (from matplotlib>=3.1.3->sweetviz) (2.8.1)
Requirement already satisfied: pytz>=2017.2 in /usr/local/lib/python3.6/dist-packages (from pandas!=1.0.0,!=1.0.1,!=1.0.2,>=0.25.3->sweetviz) (2018.9)
Requirement already satisfied: six in /usr/local/lib/python3.6/dist-packages (from cycler>=0.10->matplotlib>=3.1.3->sweetviz) (1.15.0)
Installing collected packages: tqdm, sweetviz
  Found existing installation: tqdm 4.41.1
    Uninstalling tqdm-4.41.1:
      Successfully uninstalled tqdm-4.41.1
Successfully installed sweetviz-2.0.6 tqdm-4.56.2
Collecting scikit-learn
  Downloading https://files.pythonhosted.org/packages/e2/4c/6111b9a325f29527d7f262e2ee8c730d354b47a728d955e186dacad57a0d/scikit_learn-0.24.1-cp36-cp36m-manylinux2010_x86_64.whl (22.2MB)
     |████████████████████████████████| 22.2MB 1.4MB/s
Collecting threadpoolctl>=2.0.0
  Downloading https://files.pythonhosted.org/packages/f7/12/ec3f2e203afa394a149911729357aa48affc59c20e2c1c8297a60f33f133/threadpoolctl-2.1.0-py3-none-any.whl
Requirement already satisfied, skipping upgrade: numpy>=1.13.3 in /usr/local/lib/python3.6/dist-packages (from scikit-learn) (1.19.5)
Requirement already satisfied, skipping upgrade: joblib>=0.11 in /usr/local/lib/python3.6/dist-packages (from scikit-learn) (1.0.0)
Requirement already satisfied, skipping upgrade: scipy>=0.19.1 in /usr/local/lib/python3.6/dist-packages (from scikit-learn) (1.4.1)
Installing collected packages: threadpoolctl, scikit-learn
  Found existing installation: scikit-learn 0.22.2.post1
    Uninstalling scikit-learn-0.22.2.post1:
      Successfully uninstalled scikit-learn-0.22.2.post1
Successfully installed scikit-learn-0.24.1 threadpoolctl-2.1.0
In [3]:
# import numpy, matplotlib, etc.
import numpy as np
import matplotlib.pyplot as plt
import pandas as pd
import seaborn as sns
import plotly.express as px
import plotly.graph_objects as go
from scipy.stats import norm
import math
from tqdm.auto import tqdm
import sweetviz as sw

# sklearn imports
import sklearn
from sklearn import set_config
from sklearn import metrics
from sklearn.metrics import mean_squared_error

from sklearn import linear_model
from sklearn.linear_model import LinearRegression, SGDRegressor, Lasso, ElasticNet, Ridge

from sklearn import preprocessing
from sklearn.preprocessing import OneHotEncoder, OrdinalEncoder
from sklearn.preprocessing import StandardScaler, RobustScaler
from sklearn.preprocessing import PolynomialFeatures

from sklearn import model_selection
from sklearn.model_selection import train_test_split
from sklearn.model_selection import KFold

from sklearn.compose import ColumnTransformer
from sklearn.pipeline import make_pipeline
from sklearn.feature_selection import RFE
from sklearn.ensemble import GradientBoostingRegressor

Loading the Data

In [4]:
!wget https://gist.githubusercontent.com/NisanDalva/7d86471c4af68d1b5a1cc87effe853f7/raw/b617a2e0ee4e9220d094424c142fcf86e8147245/train_house_df.csv #train set
!wget https://gist.githubusercontent.com/NisanDalva/37eb2b754cfbeb5df1ca7a0c413beb05/raw/fa930e97152ed33a031f1e29714f0438e2f3a645/test_house_df.csv #test set
house_df = pd.read_csv('train_house_df.csv')
house_df_test = pd.read_csv('test_house_df.csv')

display(house_df.head())
print(house_df.shape)
display(house_df_test.head())
print(house_df_test.shape)
--2021-02-14 18:45:10--  https://gist.githubusercontent.com/NisanDalva/7d86471c4af68d1b5a1cc87effe853f7/raw/b617a2e0ee4e9220d094424c142fcf86e8147245/train_house_df.csv
Resolving gist.githubusercontent.com (gist.githubusercontent.com)... 185.199.108.133, 185.199.109.133, 185.199.110.133, ...
Connecting to gist.githubusercontent.com (gist.githubusercontent.com)|185.199.108.133|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 460676 (450K) [text/plain]
Saving to: ‘train_house_df.csv’

train_house_df.csv  100%[===================>] 449.88K  --.-KB/s    in 0.08s

2021-02-14 18:45:10 (5.74 MB/s) - ‘train_house_df.csv’ saved [460676/460676]

--2021-02-14 18:45:11--  https://gist.githubusercontent.com/NisanDalva/37eb2b754cfbeb5df1ca7a0c413beb05/raw/fa930e97152ed33a031f1e29714f0438e2f3a645/test_house_df.csv
Resolving gist.githubusercontent.com (gist.githubusercontent.com)... 185.199.108.133, 185.199.109.133, 185.199.110.133, ...
Connecting to gist.githubusercontent.com (gist.githubusercontent.com)|185.199.108.133|:443... connected.
HTTP request sent, awaiting response... 200 OK
Length: 451405 (441K) [text/plain]
Saving to: ‘test_house_df.csv’

test_house_df.csv   100%[===================>] 440.83K  --.-KB/s    in 0.04s

2021-02-14 18:45:11 (9.89 MB/s) - ‘test_house_df.csv’ saved [451405/451405]

Id MSSubClass MSZoning LotFrontage LotArea Street Alley LotShape LandContour Utilities LotConfig LandSlope Neighborhood Condition1 Condition2 BldgType HouseStyle OverallQual OverallCond YearBuilt YearRemodAdd RoofStyle RoofMatl Exterior1st Exterior2nd MasVnrType MasVnrArea ExterQual ExterCond Foundation BsmtQual BsmtCond BsmtExposure BsmtFinType1 BsmtFinSF1 BsmtFinType2 BsmtFinSF2 BsmtUnfSF TotalBsmtSF Heating ... CentralAir Electrical 1stFlrSF 2ndFlrSF LowQualFinSF GrLivArea BsmtFullBath BsmtHalfBath FullBath HalfBath BedroomAbvGr KitchenAbvGr KitchenQual TotRmsAbvGrd Functional Fireplaces FireplaceQu GarageType GarageYrBlt GarageFinish GarageCars GarageArea GarageQual GarageCond PavedDrive WoodDeckSF OpenPorchSF EnclosedPorch 3SsnPorch ScreenPorch PoolArea PoolQC Fence MiscFeature MiscVal MoSold YrSold SaleType SaleCondition SalePrice
0 1 60 RL 65.0 8450 Pave NaN Reg Lvl AllPub Inside Gtl CollgCr Norm Norm 1Fam 2Story 7 5 2003 2003 Gable CompShg VinylSd VinylSd BrkFace 196.0 Gd TA PConc Gd TA No GLQ 706 Unf 0 150 856 GasA ... Y SBrkr 856 854 0 1710 1 0 2 1 3 1 Gd 8 Typ 0 NaN Attchd 2003.0 RFn 2 548 TA TA Y 0 61 0 0 0 0 NaN NaN NaN 0 2 2008 WD Normal 208500
1 2 20 RL 80.0 9600 Pave NaN Reg Lvl AllPub FR2 Gtl Veenker Feedr Norm 1Fam 1Story 6 8 1976 1976 Gable CompShg MetalSd MetalSd None 0.0 TA TA CBlock Gd TA Gd ALQ 978 Unf 0 284 1262 GasA ... Y SBrkr 1262 0 0 1262 0 1 2 0 3 1 TA 6 Typ 1 TA Attchd 1976.0 RFn 2 460 TA TA Y 298 0 0 0 0 0 NaN NaN NaN 0 5 2007 WD Normal 181500
2 3 60 RL 68.0 11250 Pave NaN IR1 Lvl AllPub Inside Gtl CollgCr Norm Norm 1Fam 2Story 7 5 2001 2002 Gable CompShg VinylSd VinylSd BrkFace 162.0 Gd TA PConc Gd TA Mn GLQ 486 Unf 0 434 920 GasA ... Y SBrkr 920 866 0 1786 1 0 2 1 3 1 Gd 6 Typ 1 TA Attchd 2001.0 RFn 2 608 TA TA Y 0 42 0 0 0 0 NaN NaN NaN 0 9 2008 WD Normal 223500
3 4 70 RL 60.0 9550 Pave NaN IR1 Lvl AllPub Corner Gtl Crawfor Norm Norm 1Fam 2Story 7 5 1915 1970 Gable CompShg Wd Sdng Wd Shng None 0.0 TA TA BrkTil TA Gd No ALQ 216 Unf 0 540 756 GasA ... Y SBrkr 961 756 0 1717 1 0 1 0 3 1 Gd 7 Typ 1 Gd Detchd 1998.0 Unf 3 642 TA TA Y 0 35 272 0 0 0 NaN NaN NaN 0 2 2006 WD Abnorml 140000
4 5 60 RL 84.0 14260 Pave NaN IR1 Lvl AllPub FR2 Gtl NoRidge Norm Norm 1Fam 2Story 8 5 2000 2000 Gable CompShg VinylSd VinylSd BrkFace 350.0 Gd TA PConc Gd TA Av GLQ 655 Unf 0 490 1145 GasA ... Y SBrkr 1145 1053 0 2198 1 0 2 1 4 1 Gd 9 Typ 1 TA Attchd 2000.0 RFn 3 836 TA TA Y 192 84 0 0 0 0 NaN NaN NaN 0 12 2008 WD Normal 250000

5 rows × 81 columns

(1460, 81)
Id MSSubClass MSZoning LotFrontage LotArea Street Alley LotShape LandContour Utilities LotConfig LandSlope Neighborhood Condition1 Condition2 BldgType HouseStyle OverallQual OverallCond YearBuilt YearRemodAdd RoofStyle RoofMatl Exterior1st Exterior2nd MasVnrType MasVnrArea ExterQual ExterCond Foundation BsmtQual BsmtCond BsmtExposure BsmtFinType1 BsmtFinSF1 BsmtFinType2 BsmtFinSF2 BsmtUnfSF TotalBsmtSF Heating HeatingQC CentralAir Electrical 1stFlrSF 2ndFlrSF LowQualFinSF GrLivArea BsmtFullBath BsmtHalfBath FullBath HalfBath BedroomAbvGr KitchenAbvGr KitchenQual TotRmsAbvGrd Functional Fireplaces FireplaceQu GarageType GarageYrBlt GarageFinish GarageCars GarageArea GarageQual GarageCond PavedDrive WoodDeckSF OpenPorchSF EnclosedPorch 3SsnPorch ScreenPorch PoolArea PoolQC Fence MiscFeature MiscVal MoSold YrSold SaleType SaleCondition
0 1461 20 RH 80.0 11622 Pave NaN Reg Lvl AllPub Inside Gtl NAmes Feedr Norm 1Fam 1Story 5 6 1961 1961 Gable CompShg VinylSd VinylSd None 0.0 TA TA CBlock TA TA No Rec 468.0 LwQ 144.0 270.0 882.0 GasA TA Y SBrkr 896 0 0 896 0.0 0.0 1 0 2 1 TA 5 Typ 0 NaN Attchd 1961.0 Unf 1.0 730.0 TA TA Y 140 0 0 0 120 0 NaN MnPrv NaN 0 6 2010 WD Normal
1 1462 20 RL 81.0 14267 Pave NaN IR1 Lvl AllPub Corner Gtl NAmes Norm Norm 1Fam 1Story 6 6 1958 1958 Hip CompShg Wd Sdng Wd Sdng BrkFace 108.0 TA TA CBlock TA TA No ALQ 923.0 Unf 0.0 406.0 1329.0 GasA TA Y SBrkr 1329 0 0 1329 0.0 0.0 1 1 3 1 Gd 6 Typ 0 NaN Attchd 1958.0 Unf 1.0 312.0 TA TA Y 393 36 0 0 0 0 NaN NaN Gar2 12500 6 2010 WD Normal
2 1463 60 RL 74.0 13830 Pave NaN IR1 Lvl AllPub Inside Gtl Gilbert Norm Norm 1Fam 2Story 5 5 1997 1998 Gable CompShg VinylSd VinylSd None 0.0 TA TA PConc Gd TA No GLQ 791.0 Unf 0.0 137.0 928.0 GasA Gd Y SBrkr 928 701 0 1629 0.0 0.0 2 1 3 1 TA 6 Typ 1 TA Attchd 1997.0 Fin 2.0 482.0 TA TA Y 212 34 0 0 0 0 NaN MnPrv NaN 0 3 2010 WD Normal
3 1464 60 RL 78.0 9978 Pave NaN IR1 Lvl AllPub Inside Gtl Gilbert Norm Norm 1Fam 2Story 6 6 1998 1998 Gable CompShg VinylSd VinylSd BrkFace 20.0 TA TA PConc TA TA No GLQ 602.0 Unf 0.0 324.0 926.0 GasA Ex Y SBrkr 926 678 0 1604 0.0 0.0 2 1 3 1 Gd 7 Typ 1 Gd Attchd 1998.0 Fin 2.0 470.0 TA TA Y 360 36 0 0 0 0 NaN NaN NaN 0 6 2010 WD Normal
4 1465 120 RL 43.0 5005 Pave NaN IR1 HLS AllPub Inside Gtl StoneBr Norm Norm TwnhsE 1Story 8 5 1992 1992 Gable CompShg HdBoard HdBoard None 0.0 Gd TA PConc Gd TA No ALQ 263.0 Unf 0.0 1017.0 1280.0 GasA Ex Y SBrkr 1280 0 0 1280 0.0 0.0 2 0 2 1 Gd 5 Typ 0 NaN Attchd 1992.0 RFn 2.0 506.0 TA TA Y 0 82 0 0 144 0 NaN NaN NaN 0 1 2010 WD Normal
(1459, 80)

As we can see we have 1460 samples on the train set and 1459 on the test set.
for explore the data, we use the house_df (which is the train set).

NOTE: To impute the missing values we'll use the all_df (which is the train and test sets combained).

Exploratory Data Analysis

Let's see some information about:

In [5]:
house_df.info()
<class 'pandas.core.frame.DataFrame'>
RangeIndex: 1460 entries, 0 to 1459
Data columns (total 81 columns):
 #   Column         Non-Null Count  Dtype
---  ------         --------------  -----
 0   Id             1460 non-null   int64
 1   MSSubClass     1460 non-null   int64
 2   MSZoning       1460 non-null   object
 3   LotFrontage    1201 non-null   float64
 4   LotArea        1460 non-null   int64
 5   Street         1460 non-null   object
 6   Alley          91 non-null     object
 7   LotShape       1460 non-null   object
 8   LandContour    1460 non-null   object
 9   Utilities      1460 non-null   object
 10  LotConfig      1460 non-null   object
 11  LandSlope      1460 non-null   object
 12  Neighborhood   1460 non-null   object
 13  Condition1     1460 non-null   object
 14  Condition2     1460 non-null   object
 15  BldgType       1460 non-null   object
 16  HouseStyle     1460 non-null   object
 17  OverallQual    1460 non-null   int64
 18  OverallCond    1460 non-null   int64
 19  YearBuilt      1460 non-null   int64
 20  YearRemodAdd   1460 non-null   int64
 21  RoofStyle      1460 non-null   object
 22  RoofMatl       1460 non-null   object
 23  Exterior1st    1460 non-null   object
 24  Exterior2nd    1460 non-null   object
 25  MasVnrType     1452 non-null   object
 26  MasVnrArea     1452 non-null   float64
 27  ExterQual      1460 non-null   object
 28  ExterCond      1460 non-null   object
 29  Foundation     1460 non-null   object
 30  BsmtQual       1423 non-null   object
 31  BsmtCond       1423 non-null   object
 32  BsmtExposure   1422 non-null   object
 33  BsmtFinType1   1423 non-null   object
 34  BsmtFinSF1     1460 non-null   int64
 35  BsmtFinType2   1422 non-null   object
 36  BsmtFinSF2     1460 non-null   int64
 37  BsmtUnfSF      1460 non-null   int64
 38  TotalBsmtSF    1460 non-null   int64
 39  Heating        1460 non-null   object
 40  HeatingQC      1460 non-null   object
 41  CentralAir     1460 non-null   object
 42  Electrical     1459 non-null   object
 43  1stFlrSF       1460 non-null   int64
 44  2ndFlrSF       1460 non-null   int64
 45  LowQualFinSF   1460 non-null   int64
 46  GrLivArea      1460 non-null   int64
 47  BsmtFullBath   1460 non-null   int64
 48  BsmtHalfBath   1460 non-null   int64
 49  FullBath       1460 non-null   int64
 50  HalfBath       1460 non-null   int64
 51  BedroomAbvGr   1460 non-null   int64
 52  KitchenAbvGr   1460 non-null   int64
 53  KitchenQual    1460 non-null   object
 54  TotRmsAbvGrd   1460 non-null   int64
 55  Functional     1460 non-null   object
 56  Fireplaces     1460 non-null   int64
 57  FireplaceQu    770 non-null    object
 58  GarageType     1379 non-null   object
 59  GarageYrBlt    1379 non-null   float64
 60  GarageFinish   1379 non-null   object
 61  GarageCars     1460 non-null   int64
 62  GarageArea     1460 non-null   int64
 63  GarageQual     1379 non-null   object
 64  GarageCond     1379 non-null   object
 65  PavedDrive     1460 non-null   object
 66  WoodDeckSF     1460 non-null   int64
 67  OpenPorchSF    1460 non-null   int64
 68  EnclosedPorch  1460 non-null   int64
 69  3SsnPorch      1460 non-null   int64
 70  ScreenPorch    1460 non-null   int64
 71  PoolArea       1460 non-null   int64
 72  PoolQC         7 non-null      object
 73  Fence          281 non-null    object
 74  MiscFeature    54 non-null     object
 75  MiscVal        1460 non-null   int64
 76  MoSold         1460 non-null   int64
 77  YrSold         1460 non-null   int64
 78  SaleType       1460 non-null   object
 79  SaleCondition  1460 non-null   object
 80  SalePrice      1460 non-null   int64
dtypes: float64(3), int64(35), object(43)
memory usage: 924.0+ KB

So we have 80 features of different types - float64, int64 and object.
We also have a lot of missing values, we will see later how they can be filled so that we will achieve a better result.

Some statistics of the data.

In [6]:
print('For types of `int64 or `float64`:')
display(house_df.describe().T)

display(house_df.describe(include='object').T)
For types of `int64 or `float64`:
count mean std min 25% 50% 75% max
Id 1460.0 730.500000 421.610009 1.0 365.75 730.5 1095.25 1460.0
MSSubClass 1460.0 56.897260 42.300571 20.0 20.00 50.0 70.00 190.0
LotFrontage 1201.0 70.049958 24.284752 21.0 59.00 69.0 80.00 313.0
LotArea 1460.0 10516.828082 9981.264932 1300.0 7553.50 9478.5 11601.50 215245.0
OverallQual 1460.0 6.099315 1.382997 1.0 5.00 6.0 7.00 10.0
OverallCond 1460.0 5.575342 1.112799 1.0 5.00 5.0 6.00 9.0
YearBuilt 1460.0 1971.267808 30.202904 1872.0 1954.00 1973.0 2000.00 2010.0
YearRemodAdd 1460.0 1984.865753 20.645407 1950.0 1967.00 1994.0 2004.00 2010.0
MasVnrArea 1452.0 103.685262 181.066207 0.0 0.00 0.0 166.00 1600.0
BsmtFinSF1 1460.0 443.639726 456.098091 0.0 0.00 383.5 712.25 5644.0
BsmtFinSF2 1460.0 46.549315 161.319273 0.0 0.00 0.0 0.00 1474.0
BsmtUnfSF 1460.0 567.240411 441.866955 0.0 223.00 477.5 808.00 2336.0
TotalBsmtSF 1460.0 1057.429452 438.705324 0.0 795.75 991.5 1298.25 6110.0
1stFlrSF 1460.0 1162.626712 386.587738 334.0 882.00 1087.0 1391.25 4692.0
2ndFlrSF 1460.0 346.992466 436.528436 0.0 0.00 0.0 728.00 2065.0
LowQualFinSF 1460.0 5.844521 48.623081 0.0 0.00 0.0 0.00 572.0
GrLivArea 1460.0 1515.463699 525.480383 334.0 1129.50 1464.0 1776.75 5642.0
BsmtFullBath 1460.0 0.425342 0.518911 0.0 0.00 0.0 1.00 3.0
BsmtHalfBath 1460.0 0.057534 0.238753 0.0 0.00 0.0 0.00 2.0
FullBath 1460.0 1.565068 0.550916 0.0 1.00 2.0 2.00 3.0
HalfBath 1460.0 0.382877 0.502885 0.0 0.00 0.0 1.00 2.0
BedroomAbvGr 1460.0 2.866438 0.815778 0.0 2.00 3.0 3.00 8.0
KitchenAbvGr 1460.0 1.046575 0.220338 0.0 1.00 1.0 1.00 3.0
TotRmsAbvGrd 1460.0 6.517808 1.625393 2.0 5.00 6.0 7.00 14.0
Fireplaces 1460.0 0.613014 0.644666 0.0 0.00 1.0 1.00 3.0
GarageYrBlt 1379.0 1978.506164 24.689725 1900.0 1961.00 1980.0 2002.00 2010.0
GarageCars 1460.0 1.767123 0.747315 0.0 1.00 2.0 2.00 4.0
GarageArea 1460.0 472.980137 213.804841 0.0 334.50 480.0 576.00 1418.0
WoodDeckSF 1460.0 94.244521 125.338794 0.0 0.00 0.0 168.00 857.0
OpenPorchSF 1460.0 46.660274 66.256028 0.0 0.00 25.0 68.00 547.0
EnclosedPorch 1460.0 21.954110 61.119149 0.0 0.00 0.0 0.00 552.0
3SsnPorch 1460.0 3.409589 29.317331 0.0 0.00 0.0 0.00 508.0
ScreenPorch 1460.0 15.060959 55.757415 0.0 0.00 0.0 0.00 480.0
PoolArea 1460.0 2.758904 40.177307 0.0 0.00 0.0 0.00 738.0
MiscVal 1460.0 43.489041 496.123024 0.0 0.00 0.0 0.00 15500.0
MoSold 1460.0 6.321918 2.703626 1.0 5.00 6.0 8.00 12.0
YrSold 1460.0 2007.815753 1.328095 2006.0 2007.00 2008.0 2009.00 2010.0
SalePrice 1460.0 180921.195890 79442.502883 34900.0 129975.00 163000.0 214000.00 755000.0
count unique top freq
MSZoning 1460 5 RL 1151
Street 1460 2 Pave 1454
Alley 91 2 Grvl 50
LotShape 1460 4 Reg 925
LandContour 1460 4 Lvl 1311
Utilities 1460 2 AllPub 1459
LotConfig 1460 5 Inside 1052
LandSlope 1460 3 Gtl 1382
Neighborhood 1460 25 NAmes 225
Condition1 1460 9 Norm 1260
Condition2 1460 8 Norm 1445
BldgType 1460 5 1Fam 1220
HouseStyle 1460 8 1Story 726
RoofStyle 1460 6 Gable 1141
RoofMatl 1460 8 CompShg 1434
Exterior1st 1460 15 VinylSd 515
Exterior2nd 1460 16 VinylSd 504
MasVnrType 1452 4 None 864
ExterQual 1460 4 TA 906
ExterCond 1460 5 TA 1282
Foundation 1460 6 PConc 647
BsmtQual 1423 4 TA 649
BsmtCond 1423 4 TA 1311
BsmtExposure 1422 4 No 953
BsmtFinType1 1423 6 Unf 430
BsmtFinType2 1422 6 Unf 1256
Heating 1460 6 GasA 1428
HeatingQC 1460 5 Ex 741
CentralAir 1460 2 Y 1365
Electrical 1459 5 SBrkr 1334
KitchenQual 1460 4 TA 735
Functional 1460 7 Typ 1360
FireplaceQu 770 5 Gd 380
GarageType 1379 6 Attchd 870
GarageFinish 1379 3 Unf 605
GarageQual 1379 5 TA 1311
GarageCond 1379 5 TA 1326
PavedDrive 1460 3 Y 1340
PoolQC 7 3 Gd 3
Fence 281 4 MnPrv 157
MiscFeature 54 4 Shed 49
SaleType 1460 9 WD 1267
SaleCondition 1460 6 Normal 1198

Get the numerical and categorical features.

In [7]:
def determine_dtypes(df):
  num_cols = df.select_dtypes(include=[np.int64, np.float64]).columns
  cat_cols = df.select_dtypes(include=['object', 'bool']).columns
  return num_cols, cat_cols

Target Variable

Let's take a look on the terget variable SalePrice.

In [8]:
# Get the fitted parameters used by the function norm
mu, sigma = norm.fit(house_df['SalePrice'])

fig = px.histogram(data_frame=house_df, x='SalePrice')
fig.update_layout(
    title_text=f'SalePrice distribution - mu= {mu:.3f}, sigma= {sigma:.3f}',
    xaxis_title_text='SalePrice',
    yaxis_title_text='Count',
    bargap=0.2, # gap between bars of adjacent location coordinates
)
fig.show()

We can see the most common price is between 140,000 and 149,999 dollars.

Sweetviz

Since we have a lot of features, let's use sweetviz to summarize all our data.

In [9]:
usedcars_report = sw.analyze(house_df)
usedcars_report.show_notebook(layout='vertical')

You can notice a few things:

  • We have features that are roughly normally distributed (such as 1stFlrSF, TotRmsAbvGrd and GarageArea)

  • Features that maintain a high correlation between them and the target variable (OverallQual, GrLivArea, GarageArea, GarageCars, etc.)

  • Features that maintain a really low correlation between them and the target variable (OverallCond, BsmtFinSF2, LowQualFinSF, BsmtHalfBath, etc.)

  • Features that they have one most common value - more than 90% (Street, Utilities, LandSlop, Condition2, etc.)

So I decided to drop those features that have one most common value (more than 90%), and variables that do not maintain correlation between them and the target variable or are very low (less than 0.1).

In [10]:
# will drop them later
to_drop = ['Street', 'LandContour', 'LandSlope', 'Condition1', 'Condition2',
'BsmtFinType2', 'BsmtFinSF2', 'Heating', 'CentralAir', 'Electrical', 'LowQualFinSF', 'BsmtHalfBath',
'KitchenAbvGr', 'Functional', 'PavedDrive', '3SsnPorch', 'ScreenPorch', 'PoolArea', 'PoolQC', 'Fence',
'MiscFeature', 'MiscVal', 'MoSold', 'YrSold']

Let's identify the ordinal features.

In [11]:
ordinal_features = ['OverallQual', 'OverallCond', 'LotShape', 'YearBuilt', 'YearRemodAdd', 'RoofStyle', 'RoofMatl',
                    'ExterQual', 'ExterCond', 'BsmtQual', 'BsmtCond', 'BsmtExposure', 'BsmtFinType1', 'HeatingQC',
                    'BsmtFullBath', 'FullBath', 'HalfBath', 'BedroomAbvGr', 'KitchenQual', 'GarageCars',
                    'TotRmsAbvGrd', 'Fireplaces', 'FireplaceQu', 'GarageYrBlt', 'GarageFinish', 'GarageQual',
                    'GarageCond']

Categorical Against the Target Variable

In [12]:
def plot_boxplots_by_features(df, feature, all_features):
  nrows = math.ceil(math.sqrt(len(all_features)))
  ncols = math.ceil((len(all_features)/nrows))

  fig, axes = plt.subplots(nrows, ncols, figsize=(ncols*5, nrows*3))
  axes = axes.flatten()

  pbar = tqdm(zip(all_features, axes), total=len(all_features), desc='Calculating box-plots')

  for i, j in pbar:
    sortd = df.groupby([i])[feature].median().sort_values(ascending=False)
    sns.boxplot(x=i, y=feature, data=df, palette='plasma', order=sortd.index, ax=j)
    j.tick_params(labelrotation=45)
    plt.tight_layout()
    pbar.set_description(f'Calculating box-plot {i} by {feature}')

  # remove unused axes
  for i in tqdm(range(len(all_features), nrows*ncols), total=nrows*ncols - len(all_features), desc='Removing unused axes'):
    fig.delaxes(axes[i])

numerical_features, categorical_features = determine_dtypes(house_df)

plot_boxplots_by_features(house_df, 'SalePrice', categorical_features)

Pay attention for 3 kinds of those features:

  • Features that do not so much affect the price of the house, such as LotShape, LandContour, BsmtExposure, etc.
    That is, from now on we can conclude that there is no high correlation between them and the target variable.

  • Features that do affect the target variable like BsmtQual, KitchenQual, PoolQC, MiscFeature, etc.

  • Features we do not have much information about. Like Utilities and Heating.

Correlation

Since we have a lot of features, so to make it more readble, let's take a look only on the highest correlations.
I assuming higher correlation is greater than 0.6.

In [13]:
def plot_correlation_greater_than(df, greater_than):
  sns.set(font_scale=1.1)
  corr = np.abs(df.corr())[np.abs(df.corr()) >= greater_than]
  mask = np.triu(corr.corr())
  plt.figure(figsize=(27, 18))

  ax = sns.heatmap(corr, annot=True, fmt='.2f', cmap='Blues', square=False, linewidth=1, cbar=True, vmin=0, vmax=1, mask=mask)
  # format x and y labels
  ax.set_yticklabels(ax.get_yticklabels(), rotation=0, fontsize=12)
  ax.set_xticklabels(ax.get_xticklabels(), rotation=90, fontsize=12)

  # set the x labels and ticks on top
  # ax.xaxis.tick_top()
  # ax.xaxis.set_label_position('top')
  plt.show()

def plot_correlation_greater_than_by_feature(df, feature, greater_than):
  corr = np.abs(df.corr())[df.corr() > greater_than][feature].dropna().drop(feature).to_frame()
  ax = sns.heatmap(corr, annot=True, fmt='.2f', cmap='Blues', square=False, linewidth=1, cbar=True, vmin=0, vmax=1)
  plt.show()

plot_correlation_greater_than(house_df, 0.6)

As we can see, 1stFlrSF is highly correlated with TotalBsmtSF (0.82), which it means that probably the first floor and the basement have about the same size.
GarageArea has highly correlated withGarageCars (0.88), so that means there is no unused area, the larger the area the more cars there are.

GarageYrBlt is highly correlated with YearBuilt (0.83), which it means the house and the garage are probably built in the same year, so let's take the maximum of there features.

We can also sum up the total bathrooms in the house and the total porches squared feet to one feature.

In [14]:
def change_features_based_on_corr(df):
  df['GarageArea_mul_cars'] = df['GarageArea'] * df['GarageCars']
  df['TotalSF'] = df['BsmtFinSF1'] + df['BsmtFinSF2'] + df['1stFlrSF'] + df['2ndFlrSF']
  df['TotalBathrooms'] = df['FullBath'] + 0.5 * df['HalfBath'] + df['BsmtFullBath'] + 0.5 * df['BsmtHalfBath']
  df['TotalPorchSF'] = df['OpenPorchSF'] + df['3SsnPorch'] + df['EnclosedPorch'] + df['ScreenPorch'] + df['WoodDeckSF']
  df["YearLstCnst"] = df[["YearBuilt", "YearRemodAdd"]].max(axis=1)

  to_drop.extend(['BsmtFinSF1', '1stFlrSF', '2ndFlrSF', 'BsmtFullBath', 'HalfBath', 'FullBath', 'OpenPorchSF', 'EnclosedPorch', 'WoodDeckSF', 'YearRemodAdd', 'YearBuilt'])

The target variable SalePrice has highly correlated with OverallQual, TotalBsmSF, 1stFlrSF, GrLivArea, GarageCars and GarageArea.
Let's see the distribution of there features with the target.

In [15]:
def plot_regplots_high_corr_by_feature(df, feature, high_corr):
  corr = np.abs(df.corr())[np.abs(df.corr()) > high_corr]
  corr_indexes = corr.loc[feature].dropna().drop(feature).index

  nrows = math.ceil(math.sqrt(len(corr_indexes)))
  ncols = math.ceil((len(corr_indexes)/nrows))

  fig, axes = plt.subplots(nrows, ncols, figsize=(ncols*5, nrows*3))
  axes = axes.flatten()

  for i, j in zip(corr_indexes, axes):
    sns.regplot(x=i, y=feature, data=df, ax=j, order=3, ci=None,  color='r',line_kws={'color':'black'})
    j.set_title(f'{i} by {feature}')

  # remove unused axes
  for i in range(len(corr_indexes), nrows*ncols):
    fig.delaxes(axes[i])

  plt.tight_layout()
  plt.show()


plot_regplots_high_corr_by_feature(house_df, 'SalePrice', 0.6)

We can see we have some outliers on those features which have high correlation with SalePrice, so we can remove them.

In [16]:
def remove_outliers(df):
  df.drop(df[(df['OverallQual'] < 5) & (df['SalePrice'] > 200000)].index, inplace=True)
  df.drop(df[(df['GrLivArea'] > 4000) & (df['SalePrice'] < 200000)].index, inplace=True)
  df.drop(df[(df['GarageArea'] > 1200) & (df['SalePrice'] < 200000)].index, inplace=True)
  df.drop(df[(df['TotalBsmtSF'] > 3000) & (df['SalePrice'] > 320000)].index, inplace=True)
  df.drop(df[(df['1stFlrSF'] < 3000) & (df['SalePrice'] > 600000)].index, inplace=True)
  df.drop(df[(df['1stFlrSF'] > 3000) & (df['SalePrice'] < 200000)].index, inplace=True)
  df.drop(df[(df['GarageCars'] < 4) & (df['SalePrice'] > 620000)].index, inplace=True)
  df.reset_index(inplace=True, drop=True)

remove_outliers(house_df)
In [17]:
plot_correlation_greater_than_by_feature(house_df, 'SalePrice', 0.6)

We were able to increace a little bit the correlation between GarageCars and GarageArea with the target variable.
So it seems about right to remove those outliers.

Feature Engineering

Missing values

NOTE: Although train and test are two different data, filling the missing values is done exactly the same, so we will do them together in a data called all_df

In [18]:
all_df = pd.concat([house_df, house_df_test], keys=['train', 'test']).drop(columns='SalePrice')
display(all_df)
print(all_df.shape)
Id MSSubClass MSZoning LotFrontage LotArea Street Alley LotShape LandContour Utilities LotConfig LandSlope Neighborhood Condition1 Condition2 BldgType HouseStyle OverallQual OverallCond YearBuilt YearRemodAdd RoofStyle RoofMatl Exterior1st Exterior2nd MasVnrType MasVnrArea ExterQual ExterCond Foundation BsmtQual BsmtCond BsmtExposure BsmtFinType1 BsmtFinSF1 BsmtFinType2 BsmtFinSF2 BsmtUnfSF TotalBsmtSF Heating HeatingQC CentralAir Electrical 1stFlrSF 2ndFlrSF LowQualFinSF GrLivArea BsmtFullBath BsmtHalfBath FullBath HalfBath BedroomAbvGr KitchenAbvGr KitchenQual TotRmsAbvGrd Functional Fireplaces FireplaceQu GarageType GarageYrBlt GarageFinish GarageCars GarageArea GarageQual GarageCond PavedDrive WoodDeckSF OpenPorchSF EnclosedPorch 3SsnPorch ScreenPorch PoolArea PoolQC Fence MiscFeature MiscVal MoSold YrSold SaleType SaleCondition
train 0 1 60 RL 65.0 8450 Pave NaN Reg Lvl AllPub Inside Gtl CollgCr Norm Norm 1Fam 2Story 7 5 2003 2003 Gable CompShg VinylSd VinylSd BrkFace 196.0 Gd TA PConc Gd TA No GLQ 706.0 Unf 0.0 150.0 856.0 GasA Ex Y SBrkr 856 854 0 1710 1.0 0.0 2 1 3 1 Gd 8 Typ 0 NaN Attchd 2003.0 RFn 2.0 548.0 TA TA Y 0 61 0 0 0 0 NaN NaN NaN 0 2 2008 WD Normal
1 2 20 RL 80.0 9600 Pave NaN Reg Lvl AllPub FR2 Gtl Veenker Feedr Norm 1Fam 1Story 6 8 1976 1976 Gable CompShg MetalSd MetalSd None 0.0 TA TA CBlock Gd TA Gd ALQ 978.0 Unf 0.0 284.0 1262.0 GasA Ex Y SBrkr 1262 0 0 1262 0.0 1.0 2 0 3 1 TA 6 Typ 1 TA Attchd 1976.0 RFn 2.0 460.0 TA TA Y 298 0 0 0 0 0 NaN NaN NaN 0 5 2007 WD Normal
2 3 60 RL 68.0 11250 Pave NaN IR1 Lvl AllPub Inside Gtl CollgCr Norm Norm 1Fam 2Story 7 5 2001 2002 Gable CompShg VinylSd VinylSd BrkFace 162.0 Gd TA PConc Gd TA Mn GLQ 486.0 Unf 0.0 434.0 920.0 GasA Ex Y SBrkr 920 866 0 1786 1.0 0.0 2 1 3 1 Gd 6 Typ 1 TA Attchd 2001.0 RFn 2.0 608.0 TA TA Y 0 42 0 0 0 0 NaN NaN NaN 0 9 2008 WD Normal
3 4 70 RL 60.0 9550 Pave NaN IR1 Lvl AllPub Corner Gtl Crawfor Norm Norm 1Fam 2Story 7 5 1915 1970 Gable CompShg Wd Sdng Wd Shng None 0.0 TA TA BrkTil TA Gd No ALQ 216.0 Unf 0.0 540.0 756.0 GasA Gd Y SBrkr 961 756 0 1717 1.0 0.0 1 0 3 1 Gd 7 Typ 1 Gd Detchd 1998.0 Unf 3.0 642.0 TA TA Y 0 35 272 0 0 0 NaN NaN NaN 0 2 2006 WD Abnorml
4 5 60 RL 84.0 14260 Pave NaN IR1 Lvl AllPub FR2 Gtl NoRidge Norm Norm 1Fam 2Story 8 5 2000 2000 Gable CompShg VinylSd VinylSd BrkFace 350.0 Gd TA PConc Gd TA Av GLQ 655.0 Unf 0.0 490.0 1145.0 GasA Ex Y SBrkr 1145 1053 0 2198 1.0 0.0 2 1 4 1 Gd 9 Typ 1 TA Attchd 2000.0 RFn 3.0 836.0 TA TA Y 192 84 0 0 0 0 NaN NaN NaN 0 12 2008 WD Normal
... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ...
test 1454 2915 160 RM 21.0 1936 Pave NaN Reg Lvl AllPub Inside Gtl MeadowV Norm Norm Twnhs 2Story 4 7 1970 1970 Gable CompShg CemntBd CmentBd None 0.0 TA TA CBlock TA TA No Unf 0.0 Unf 0.0 546.0 546.0 GasA Gd Y SBrkr 546 546 0 1092 0.0 0.0 1 1 3 1 TA 5 Typ 0 NaN NaN NaN NaN 0.0 0.0 NaN NaN Y 0 0 0 0 0 0 NaN NaN NaN 0 6 2006 WD Normal
1455 2916 160 RM 21.0 1894 Pave NaN Reg Lvl AllPub Inside Gtl MeadowV Norm Norm TwnhsE 2Story 4 5 1970 1970 Gable CompShg CemntBd CmentBd None 0.0 TA TA CBlock TA TA No Rec 252.0 Unf 0.0 294.0 546.0 GasA TA Y SBrkr 546 546 0 1092 0.0 0.0 1 1 3 1 TA 6 Typ 0 NaN CarPort 1970.0 Unf 1.0 286.0 TA TA Y 0 24 0 0 0 0 NaN NaN NaN 0 4 2006 WD Abnorml
1456 2917 20 RL 160.0 20000 Pave NaN Reg Lvl AllPub Inside Gtl Mitchel Norm Norm 1Fam 1Story 5 7 1960 1996 Gable CompShg VinylSd VinylSd None 0.0 TA TA CBlock TA TA No ALQ 1224.0 Unf 0.0 0.0 1224.0 GasA Ex Y SBrkr 1224 0 0 1224 1.0 0.0 1 0 4 1 TA 7 Typ 1 TA Detchd 1960.0 Unf 2.0 576.0 TA TA Y 474 0 0 0 0 0 NaN NaN NaN 0 9 2006 WD Abnorml
1457 2918 85 RL 62.0 10441 Pave NaN Reg Lvl AllPub Inside Gtl Mitchel Norm Norm 1Fam SFoyer 5 5 1992 1992 Gable CompShg HdBoard Wd Shng None 0.0 TA TA PConc Gd TA Av GLQ 337.0 Unf 0.0 575.0 912.0 GasA TA Y SBrkr 970 0 0 970 0.0 1.0 1 0 3 1 TA 6 Typ 0 NaN NaN NaN NaN 0.0 0.0 NaN NaN Y 80 32 0 0 0 0 NaN MnPrv Shed 700 7 2006 WD Normal
1458 2919 60 RL 74.0 9627 Pave NaN Reg Lvl AllPub Inside Mod Mitchel Norm Norm 1Fam 2Story 7 5 1993 1994 Gable CompShg HdBoard HdBoard BrkFace 94.0 TA TA PConc Gd TA Av LwQ 758.0 Unf 0.0 238.0 996.0 GasA Ex Y SBrkr 996 1004 0 2000 0.0 0.0 2 1 3 1 TA 9 Typ 1 TA Attchd 1993.0 Fin 3.0 650.0 TA TA Y 190 48 0 0 0 0 NaN NaN NaN 0 11 2006 WD Normal

2908 rows × 80 columns

(2908, 80)

We have 2908 samples at all (after removing the outliers).

Now we need to check if we have NaN values.
there are 3 different kinds of NaN values:

  1. '' - an empty string
  2. None - an empty value of python
  3. np.NaN - a numpy empty value

To do so, since we don't know how look a nan values on this dataset, we would like to change all empty values to np.NaN value.

In [19]:
def change_NaNs(df):
  df.replace('', np.NaN, inplace=True)
  df.fillna(np.NaN, inplace=True)

change_NaNs(all_df)

Let's see in which features has NaN values at all.

In [19]:

In [20]:
def check_NaNs_values(df):
  all = df.isnull().sum().sort_values(ascending=False)
  count = all[all != 0]
  percent = (count/len(df)) * 100
  dtypes = df.dtypes[count.index]

  return pd.concat([count, percent, dtypes], axis=1, keys=['count', 'percent', 'dtype'])
  # return pd.concat([count, percent], axis=1, keys=['count', 'percent'])

check_NaNs_values(all_df)
Out[20]:
count percent dtype
PoolQC 2900 99.724897 object
MiscFeature 2804 96.423659 object
Alley 2710 93.191197 object
Fence 2338 80.398900 object
FireplaceQu 1419 48.796424 object
LotFrontage 483 16.609354 float64
GarageCond 159 5.467675 object
GarageQual 159 5.467675 object
GarageYrBlt 159 5.467675 float64
GarageFinish 159 5.467675 object
GarageType 157 5.398900 object
BsmtCond 82 2.819807 object
BsmtExposure 82 2.819807 object
BsmtQual 81 2.785420 object
BsmtFinType2 80 2.751032 object
BsmtFinType1 79 2.716644 object
MasVnrType 24 0.825309 object
MasVnrArea 23 0.790922 float64
MSZoning 4 0.137552 object
BsmtHalfBath 2 0.068776 float64
Utilities 2 0.068776 object
Functional 2 0.068776 object
BsmtFullBath 2 0.068776 float64
BsmtFinSF1 1 0.034388 float64
Exterior1st 1 0.034388 object
Exterior2nd 1 0.034388 object
BsmtFinSF2 1 0.034388 float64
BsmtUnfSF 1 0.034388 float64
TotalBsmtSF 1 0.034388 float64
SaleType 1 0.034388 object
Electrical 1 0.034388 object
KitchenQual 1 0.034388 object
GarageArea 1 0.034388 float64
GarageCars 1 0.034388 float64

PoolQC

Let's take a look on this pie chart:

In [21]:
def plot_sunburst_with_NaNs(df, col1, col2):
  # col1 has NaN values
  cp = df.copy()
  cp[col1] = cp[col1].apply(lambda x: 'NaN' if x is np.NaN else x) # because sunburst can't work with np.NaN
  # all_df_cp.insert(len(all_df_cp.columns), "count", 1, True)

  fig = px.sunburst(cp, path=[col1, col2], width=500, height=500)
  # fig.update_layout(margin=dict(t=10, l=10, r=10, b=10))
  fig.show()

plot_sunburst_with_NaNs(all_df, 'PoolQC', 'PoolArea')

As we see, on this dataset we have 2900 unkown values on PoolQC featrue against 2897 with no pool at all (the pool area is zero).
So, according to data_description.txt file from kaggel if there are no pool, the value of PoolQC supposed to be NA (which it means 'No Pool').
For the rest 3 values, we will fill them randomly.

Set NA for correct samples:

In [22]:
all_df.loc[((all_df['PoolQC'].isnull()) & (all_df['PoolArea'] == 0)), 'PoolQC'] = 'NA'

Those smapels we need to fill randomly.

In [23]:
display(all_df[['PoolQC', 'PoolArea']][all_df['PoolQC'].isnull()])
PoolQC PoolArea
test 960 NaN 368
1043 NaN 444
1139 NaN 561

Pay attention those 3 samples are from the test set, so it won't change the evaluation.

Define two methods who fill NaNs values, the first one fill from specific column, the second one fill from specific list.

In [24]:
def fill_na_random_pick_column_distribution(df, column_name):
    df_not_null = df[~df[column_name].isnull()]
    df[column_name] = df[column_name].apply(lambda x: np.random.choice(df_not_null[column_name]) if pd.isnull(x) else x)

def fill_na_random_from_list(df, column_name, fill_from):
  df[column_name] = df[column_name].apply(lambda x: np.random.choice(fill_from) if pd.isnull(x) else x)

options = ['Ex', 'Fa', 'Gd']
fill_na_random_from_list(all_df, 'PoolQC', options)

Now we don't have NaN values in this feature.

In [25]:
# fig = px.sunburst(all_df, path=['PoolQC', 'PoolArea'])
# fig.update_layout(margin=dict(t=10, l=10, r=10, b=10))
# fig.show()
# print(all_df['PoolQC'].isnull().any())

plot_sunburst_with_NaNs(all_df, 'PoolQC', 'PoolArea')
print(all_df['PoolQC'].isnull().any())
False

MiscFeature

Let's take a look on this pie chart:

In [26]:
plot_sunburst_with_NaNs(all_df, 'MiscFeature', 'MiscVal')

As we see, on this dataset we have 2814 unkown values on MiscFeature featrue against 2813 with no value at all (the misc values is zero).
So, according to data_description.txt file from kaggel if there are no misc value, the value of MiscFeature supposed to be NA (which it means 'None').
For the rest 1 value, we will fill it randomly.

Set NA for correct samples:

In [27]:
all_df.loc[((all_df['MiscFeature'].isnull()) & (all_df['MiscVal'] == 0)), 'MiscFeature'] = 'NA'

This smaple we need to fill randomly.

In [28]:
display(all_df[['MiscFeature', 'MiscVal']][all_df['MiscFeature'].isnull()])
MiscFeature MiscVal
test 1089 NaN 17000

Pay attention those 3 samples are from the test set, so it won't change the evaluation.

In [29]:
options = ['Elev', 'Gar2', 'Othr', 'Shed', 'TenC']
fill_na_random_from_list(all_df, 'MiscFeature', options)

Now we don't have NaN values in this feature.

In [30]:
plot_sunburst_with_NaNs(all_df, 'MiscFeature', 'MiscVal')
print(all_df['MiscFeature'].isnull().any())
False

Alley

According to data_description.txt file from kaggel if there are no Alley value, the value of Alley supposed to be NA (which it means no alley access at all).
So let's fill all the NaN values by NA.

In [31]:
all_df['Alley'] = all_df['Alley'].fillna('NA')

Fence

According to data_description.txt file from kaggel if there are no Fence value, the value of Fence supposed to be NA (which it means no fence at all).
So let's fill all the NaN values by NA.

In [32]:
all_df['Fence'] = all_df['Fence'].fillna('NA')

FireplaceQu

According to data_description.txt file from kaggel if there are no FireplaceQu value, the value of FireplaceQu supposed to be NA (which it means no fireplace at all).
So let's fill all the NaN values by NA.

In [33]:
all_df['FireplaceQu'] = all_df['FireplaceQu'].fillna('NA')

LotFrontage

Since the area of each street connected to the house property, most likely have a similar area to other houses in its neighborhood.
Let's fill in missing values by the median LotFrontage of the neighborhood.

In [34]:
#Group by neighborhood and fill in missing value by the median LotFrontage of all the neighborhood
all_df["LotFrontage"] = all_df.groupby("Neighborhood")["LotFrontage"].transform(lambda x: x.fillna(x.median()))

GarageType, GarageFinish, GarageQual and GarageCond

According to data_description.txt file from kaggel if there are no values in GarageType, GarageFinish, GarageQual and GarageCond, the values of thos features supposed to be NA (which it means no garage at all).
So let's fill all the NaN values by NA.

In [35]:
for col in ['GarageType', 'GarageFinish', 'GarageQual', 'GarageCond']:
    all_df[col] = all_df[col].fillna('NA')

GarageYrBlt, GarageArea and GarageCars

Since there are no garage when the value GarageType is NA, its mean no cars in such garage.
So let's fill all the NaN values by 0.

In [36]:
for col in ['GarageYrBlt', 'GarageArea', 'GarageCars']:
    all_df[col] = all_df[col].fillna(0)

BsmtExposure, BsmtCond, BsmtQual ,BsmtFinType2 and BsmtFinType1

According to data_description.txt file from kaggel if there are no values in BsmtExposure, BsmtCond, BsmtQual, BsmtFinType2 and BsmtFinType1 the values of thos features supposed to be NA (which it means no basemant at all).
So let's fill all the NaN values by NA.

In [37]:
for col in ['BsmtExposure', 'BsmtCond', 'BsmtQual', 'BsmtFinType2', 'BsmtFinType1']:
    all_df[col] = all_df[col].fillna('NA')

BsmtFinSF1, BsmtFinSF2, BsmtUnfSF, TotalBsmtSF, BsmtFullBath and BsmtHalfBath

Since are no values in BsmtExposure, BsmtCond, BsmtQual, BsmtFinType2 or BsmtFinType1 it means there are no basement at all.
So let's fill all the NaN values by 0.

In [38]:
for col in ['BsmtFinSF1', 'BsmtFinSF2', 'BsmtUnfSF','TotalBsmtSF', 'BsmtFullBath', 'BsmtHalfBath']:
    all_df[col] = all_df[col].fillna(0)

MasVnrArea and MasVnrType

According to data_description.txt file from kaggel if there are no values in MasVnrArea the values of this feature supposed to be None (which it means no Masonry veneer type at all).
So let's fill all the NaN values in MasVnrArea by None, and all the NaN values in MasVnrArea by 0.

In [39]:
all_df['MasVnrType'] = all_df['MasVnrType'].fillna('None')
all_df['MasVnrArea'] = all_df['MasVnrArea'].fillna(0)

MSZoning, Functional, Electrical, Exterior1st, Exterior2nd, KitchenQual and SaleType

For all these features there are between 1 and 2 NaN values, and there is no instruction in the data_description.txt file.
So let's fill them randomly.

In [40]:
for col in ['MSZoning', 'Functional', 'Electrical', 'Exterior1st', 'Exterior2nd', 'KitchenQual', 'SaleType']:
  fill_na_random_pick_column_distribution(all_df, col)

Utilities

Let's take a look on this pie chart:

In [41]:
def create_pie_chart_of_count(df, column_name):
    df_not_null = df[~df[column_name].isnull()]
    fig = px.pie(df_not_null.groupby([column_name]).size().reset_index(name='count'), names=column_name, values='count',
                 width=400, height=400)
    fig.show()

create_pie_chart_of_count(all_df, 'Utilities')

We can see there is only one values with NoSeWa and the rest is AllPub.
The only one NoSeWa is from house_df (the train set):

In [42]:
create_pie_chart_of_count(house_df, 'Utilities')

So, we can understand that since the house with NoSeWa is on the train set, this feature won't help us to predict the target.
So let's remove it.

In [43]:
all_df.drop(labels='Utilities', axis=1, inplace=True)

Now we don't have missing values at all. (Except the SalePrice from the train set)

In [44]:
check_NaNs_values(all_df)
Out[44]:
count percent dtype

Now we don't have missing values at all!

Prepare the Data and Create New Features

In [45]:
print(all_df.isnull().sum().sum())
print(all_df.shape)
0
(2908, 79)

Let's create more features based on different approaches.

Create a boolean features which 1 is availble and 0 is not.

In [46]:
def create_boolean_features(df):
  df['HasPool'] = df['PoolArea'].apply(lambda x: 1 if x > 0 else 0)
  df['Has2ndFloor'] = df['2ndFlrSF'].apply(lambda x: 1 if x > 0 else 0)
  df['HasGarage'] = df['GarageArea'].apply(lambda x: 1 if x > 0 else 0)
  df['HasBsmt'] = df['TotalBsmtSF'].apply(lambda x: 1 if x > 0 else 0)
  df['HasFireplace'] = df['Fireplaces'].apply(lambda x: 1 if x > 0 else 0)

  to_drop.extend(['Fireplaces'])

Convert some numerical features that actually categorical .

In [47]:
def set_as_categorical(df):
  df['MSSubClass'] = df['MSSubClass'].apply(str)
  df['OverallCond'] = df['OverallCond'].astype(str)
  df['YrSold'] = df['YrSold'].astype(str)
  df['MoSold'] = df['MoSold'].astype(str)

Create features based on sum of quality and conditions.

In [48]:
def features_based_on_quality_and_conditions(df):
  df['TotalExtQual'] = (df['ExterQual'] + df['ExterCond'])
  df['TotalBsmQual'] = df['BsmtQual'] + df['BsmtCond']
  df['TotalGrgQual'] = df['GarageQual'] + df['GarageCond']
  df['TotalQual'] = df['OverallQual'] + df['TotalExtQual'] + df['TotalBsmQual'] + df['TotalGrgQual'] + df['KitchenQual'] + df['HeatingQC']

  ordinal_features.extend(['TotalExtQual', 'TotalBsmQual', 'TotalGrgQual', 'TotalQual'])
  to_drop.extend(['ExterQual', 'ExterCond', 'BsmtQual', 'BsmtCond',
                  'GarageQual', 'GarageCond', 'KitchenQual', 'HeatingQC'])

Let's split back the data and remove the unneunnecessary variable Id.

In [49]:
house_df_train_not_null = all_df.loc['train'].copy().join(house_df['SalePrice'])
house_df_test_not_null = all_df.loc['test'].copy()

id_train = house_df['Id']
id_test = house_df_test['Id']

house_df_train_not_null.drop(columns='Id', inplace=True)
house_df_test_not_null.drop(columns='Id', inplace=True)

Convert the ordinal features:

In [50]:
def ordinal_encode(df, ord_features):
  oe = OrdinalEncoder(dtype=np.int64)
  oe_df = pd.DataFrame(oe.fit_transform(df.loc[:, ord_features]), columns=ord_features)
  return pd.concat([df.drop(columns=ord_features), oe_df], axis=1)

house_df_train_not_null = ordinal_encode(house_df_train_not_null, ordinal_features)
house_df_test_not_null = ordinal_encode(house_df_test_not_null, ordinal_features)
In [51]:
print(house_df_train_not_null.isnull().sum().sum())
print(house_df_train_not_null.shape)
print('\n')
print(house_df_test_not_null.isnull().sum().sum())
print(house_df_test_not_null.shape)
0
(1449, 79)


0
(1459, 78)

So let's execute all our preparing:

In [52]:
def feature_engineering(df):
  change_features_based_on_corr(df)
  create_boolean_features(df)
  set_as_categorical(df)
  features_based_on_quality_and_conditions(df)

  df.drop(columns=to_drop, inplace=True)

feature_engineering(house_df_train_not_null)
feature_engineering(house_df_test_not_null)
In [53]:
print(house_df_train_not_null.isnull().sum().sum())
print(house_df_train_not_null.shape)
print('\n')
print(house_df_test_not_null.isnull().sum().sum())
print(house_df_test_not_null.shape)
0
(1449, 49)


0
(1459, 48)

Modeling

Let's start to build our model.

In [54]:
X = house_df_train_not_null.drop(columns='SalePrice')
t = house_df_train_not_null['SalePrice']

# encode a given dataframe
def encode(df):
  numerical_cols, categorical_cols = determine_dtypes(df)

  ct_enc_std = ColumnTransformer([
            ("encoding", OrdinalEncoder(), categorical_cols),
            ("standard", StandardScaler(), numerical_cols)])

  df_encoded = pd.DataFrame(ct_enc_std.fit_transform(df))
  return df_encoded
In [55]:
print(X.isnull().sum().sum())
print(X.shape)
0
(1449, 48)

Define a method that calculate the CV. (A bit changed from Aviad's notebook)

In [56]:
def get_cv_score_and_loss(X, t, model_name, model, k=None, show_score_loss_graphs=False, use_pbar=True):
    scores_losses_df = pd.DataFrame(columns=['fold_id', 'split', 'score', 'loss'])

    if k is not None:
        cv = KFold(n_splits=k, shuffle=True, random_state=1)
    else:
        raise ValueError('you need to specify k in order for the cv to work')

    if use_pbar:
        pbar = tqdm(desc=f'Computing Model {model_name}', total=cv.get_n_splits(X))

    for i, (train_ids, val_ids) in enumerate(cv.split(X)):
        X_train = X.iloc[train_ids]
        t_train = t.iloc[train_ids]
        X_val = X.iloc[val_ids]
        t_val = t.iloc[val_ids]

        model.fit(X_train, t_train)

        y_train = model.predict(X_train)
        y_val = model.predict(X_val)
        scores_losses_df.loc[len(scores_losses_df)] = [i, 'train', model.score(X_train, t_train), mean_squared_error(t_train, y_train, squared=False)]
        scores_losses_df.loc[len(scores_losses_df)] = [i, 'val', model.score(X_val, t_val), mean_squared_error(t_val, y_val, squared=False)]

        if use_pbar:
            pbar.update()

    if use_pbar:
        pbar.close()

    val_scores_losses_df = scores_losses_df[scores_losses_df['split']=='val']
    train_scores_losses_df = scores_losses_df[scores_losses_df['split']=='train']

    mean_val_score = val_scores_losses_df['score'].mean()
    mean_val_loss = val_scores_losses_df['loss'].mean()
    mean_train_score = train_scores_losses_df['score'].mean()
    mean_train_loss = train_scores_losses_df['loss'].mean()


    fig_score = px.line(scores_losses_df, x='fold_id', y='score', color='split', title=f'Model name: {model_name}, Mean Val Score: {mean_val_score:.2f}, Mean Train Score: {mean_train_score:.2f}')
    fig_loss = px.line(scores_losses_df, x='fold_id', y='loss', color='split', title=f'Model name: {model_name}, Mean Val Loss: {mean_val_loss:.2f}, Mean Train Loss: {mean_train_loss:.2f}')
    if show_score_loss_graphs:
        fig_loss.show()
        fig_score.show()

    return mean_val_score, mean_val_loss, mean_train_score, mean_train_loss, fig_score, fig_loss

Pick an Estimator

Let's begin with find the best algorithm for our data.

In [57]:
# all models
hp_models = {
             'SGD Regressor': SGDRegressor(random_state=1, ),
             'LinearRegression': LinearRegression(),
             'Ridge': make_pipeline(RobustScaler(), Ridge()),
             'Lasso': make_pipeline(RobustScaler(), Lasso(random_state=1)),
             'Elastic Net': make_pipeline(RobustScaler(), ElasticNet(random_state=1, alpha=0.05)),
             'Gradient Boosting Regressor': GradientBoostingRegressor(n_estimators=100, learning_rate=0.05,
                                                                       max_depth=4, max_features='sqrt',
                                                                       min_samples_leaf=15, min_samples_split=10,
                                                                       loss='huber', random_state =5)
             }
In [58]:
%%time
def get_models_score_and_loss(X, t, models, numerical_cols, categorical_cols):
  # a DataFrame to save results
  results = pd.DataFrame(columns=['mean val score', 'mean val loss', 'mean train score', 'mean train loss', 'fig_score', 'fig_loss'],
                         index=hp_models.keys())

  pbar = tqdm(models.items(), total=len(models.keys()))

  for model_name, model in pbar:
    pbar.set_description(f'Calculating model {model_name}')
    preprocessor = ColumnTransformer([
                                      ("onehot", OneHotEncoder(sparse=False, handle_unknown='ignore'), categorical_cols),
                                      ("standard", StandardScaler(), numerical_cols)
    ])
    pipe = make_pipeline(preprocessor, model)

    val_score, val_loss, train_score, train_loss , fig_score, fig_loss = get_cv_score_and_loss(X, t, model_name, pipe, k=10,
                                                                                               show_score_loss_graphs=False, use_pbar=False)
    results.loc[model_name] = [val_score, val_loss, train_score, train_loss, fig_score, fig_loss]

  return results

numerical_features, categorical_features = determine_dtypes(X)

res = get_models_score_and_loss(X, t, hp_models, numerical_features, categorical_features)
/usr/local/lib/python3.6/dist-packages/sklearn/linear_model/_coordinate_descent.py:532: ConvergenceWarning:

Objective did not converge. You might want to increase the number of iterations. Duality gap: 195894588955.5289, tolerance: 704529210.9405098

/usr/local/lib/python3.6/dist-packages/sklearn/linear_model/_coordinate_descent.py:532: ConvergenceWarning:

Objective did not converge. You might want to increase the number of iterations. Duality gap: 194727189382.7591, tolerance: 698200780.974271

/usr/local/lib/python3.6/dist-packages/sklearn/linear_model/_coordinate_descent.py:532: ConvergenceWarning:

Objective did not converge. You might want to increase the number of iterations. Duality gap: 182319050872.43262, tolerance: 722691351.2660913

/usr/local/lib/python3.6/dist-packages/sklearn/linear_model/_coordinate_descent.py:532: ConvergenceWarning:

Objective did not converge. You might want to increase the number of iterations. Duality gap: 198032427043.66953, tolerance: 720561941.7667595

/usr/local/lib/python3.6/dist-packages/sklearn/linear_model/_coordinate_descent.py:532: ConvergenceWarning:

Objective did not converge. You might want to increase the number of iterations. Duality gap: 189762369420.84918, tolerance: 692783877.523433

/usr/local/lib/python3.6/dist-packages/sklearn/linear_model/_coordinate_descent.py:532: ConvergenceWarning:

Objective did not converge. You might want to increase the number of iterations. Duality gap: 196165236846.0208, tolerance: 685559096.4267876

/usr/local/lib/python3.6/dist-packages/sklearn/linear_model/_coordinate_descent.py:532: ConvergenceWarning:

Objective did not converge. You might want to increase the number of iterations. Duality gap: 172802889054.77625, tolerance: 729708893.9676858

/usr/local/lib/python3.6/dist-packages/sklearn/linear_model/_coordinate_descent.py:532: ConvergenceWarning:

Objective did not converge. You might want to increase the number of iterations. Duality gap: 166794794507.54858, tolerance: 740390599.4771714

/usr/local/lib/python3.6/dist-packages/sklearn/linear_model/_coordinate_descent.py:532: ConvergenceWarning:

Objective did not converge. You might want to increase the number of iterations. Duality gap: 190059723117.10464, tolerance: 727541166.0744317

/usr/local/lib/python3.6/dist-packages/sklearn/linear_model/_coordinate_descent.py:532: ConvergenceWarning:

Objective did not converge. You might want to increase the number of iterations. Duality gap: 212135553049.21378, tolerance: 736391573.8867512

CPU times: user 20.3 s, sys: 9.67 s, total: 29.9 s
Wall time: 19.5 s

These warnings are because we have reached the maximum number of iterations in ElasticNet model.

In [59]:
# show all results
display(res.iloc[:, :-2])

# show the graphs for the best one of val score
res.iloc[np.argmax(res['mean val score'])]['fig_score'].show()
res.iloc[np.argmax(res['mean val score'])]['fig_loss'].show()
mean val score mean val loss mean train score mean train loss
SGD Regressor 0.897045 23230.5 0.916782 21368.8
LinearRegression -5.86465e+20 1.06413e+15 0.922992 20555.8
Ridge 0.895622 23457.4 0.922656 20600.6
Lasso 0.891558 23937.4 0.922995 20555.4
Elastic Net 0.895702 23403.2 0.91206 21965.9
Gradient Boosting Regressor 0.886081 24589.9 0.919996 20950

Pick from the table the best model (Relative to mean score val).

In [60]:
best_model = hp_models[res.iloc[np.argmax(res['mean val score'])].to_frame().columns[0]]

best_model_name = res.iloc[np.argmax(res['mean val score'])].name

print(best_model_name)
print(best_model)
SGD Regressor
SGDRegressor(random_state=1)

As we can see the best result we got with SGDRegressor algorithm.
So we will keep use it.

Polynomial Degree

Let's see if we can get better results by increasing the degree.

In [61]:
%%time
# show graph of score and loss by plynomial degree of numerical features
def show_degree_graphs_cv_train(X, t, model_name, model, k=None, p=None, max_degree=10):
    numerical_cols, categorical_cols = determine_dtypes(X)

    val_train_score_loss_df = pd.DataFrame(columns=['degree', 'split', 'score', 'loss'])
    for i in tqdm(range(1, max_degree), desc='Poly Degree'):
        ct_enc_std_poly = ColumnTransformer([
            ("encoding", OneHotEncoder(sparse=False, handle_unknown='ignore'), categorical_cols),
            ("standard_poly", make_pipeline(PolynomialFeatures(degree=i), StandardScaler()), numerical_cols)])
        model_pipe = make_pipeline(ct_enc_std_poly, model)
        val_score, val_loss, train_score, train_loss , fig_score, fig_loss = get_cv_score_and_loss(X, t, model_name, model_pipe, k=k, show_score_loss_graphs=False, use_pbar=False)
        val_train_score_loss_df.loc[len(val_train_score_loss_df)] = [i, 'train', train_score, train_loss]
        val_train_score_loss_df.loc[len(val_train_score_loss_df)] = [i, 'cv', val_score, val_loss]

    fig = px.line(val_train_score_loss_df, x='degree', y='score', color='split')
    fig.show()
    fig = px.line(val_train_score_loss_df, x='degree', y='loss', color='split')
    fig.show()


show_degree_graphs_cv_train(X, t, best_model_name, best_model, k=10 ,max_degree=5)
CPU times: user 2min 15s, sys: 11.9 s, total: 2min 27s
Wall time: 2min 14s

Since we a lot of features, make them squared and even more caused a dimensional explosion and it's really bad for our data.
So it's absolutely clear that we will stay with degree=1.

Feature Selection

We want to choose the best features of our data to get best results of prediction.
We'll use RFE method from sklearn package that actually use Backward Feature Selection algorithm (i.e we start from the full feature set and remove features until we reach the number of minimum features or until we reach the best score).

So let's define a method who calculate a best number of features to select, and shows the appropriate graph.

In [62]:
%%time
def feature_selection(X, t, model_name, model):
  X_encoded = encode(X)

  results_df = pd.DataFrame(columns=['num_of_features', 'mean_val_score', 'mean_val_loss', 'mean_train_score', 'mean_train_loss', 'best_features'])

  pbar = tqdm(range(10, len(X_encoded.columns) + 1), total=len(X_encoded.columns)+1 - 10)
  for i in pbar:
    pbar.set_description(f'Calculating for {i} features')
    selector = RFE(model, n_features_to_select=i).fit(X_encoded, t)
    mean_val_score, mean_val_loss, mean_train_score, mean_train_loss, fig_score, fig_loss = get_cv_score_and_loss(X_encoded, t, model_name, selector, k=10, use_pbar=False)
    if mean_val_score < 0:
      break
    results_df.loc[len(results_df)] = [i, mean_val_score, mean_val_loss, mean_train_score, mean_train_loss, selector.support_]

  fig = go.Figure()
  fig.add_trace(go.Scatter(x=results_df['num_of_features'], y=results_df['mean_val_score']))
  fig.update_xaxes(title_text='Number of features selected')
  fig.update_yaxes(title_text='Cross validation score')
  fig.show()

  return results_df


results_scores = feature_selection(X, t, best_model_name, best_model)
CPU times: user 6min, sys: 18.2 s, total: 6min 19s
Wall time: 6min

The algorithm founds that after 25 features we reach a negative score, so we stopped it.

In [63]:
display(results_scores.iloc[:, :-1])
num_of_features mean_val_score mean_val_loss mean_train_score mean_train_loss
0 10 0.826357 30132.633909 0.844086 29229.566804
1 11 0.832617 29688.208902 0.847218 28933.202312
2 12 0.838027 29200.648193 0.851121 28562.936267
3 13 0.835651 29367.863167 0.850764 28600.750388
4 14 0.835944 29315.682990 0.852460 28444.421842
5 15 0.840224 28931.645370 0.856411 28060.909335
6 16 0.845123 28528.310231 0.859312 27765.826535
7 17 0.847931 28245.564364 0.861256 27571.268038
8 18 0.849462 28112.001254 0.862047 27491.980521
9 19 0.849468 28071.526651 0.862249 27472.457520
10 20 0.850597 27969.114781 0.863715 27332.970699
11 21 0.850588 27942.109529 0.863819 27321.911045
12 22 0.851243 27856.947284 0.864669 27234.622058
13 23 0.848497 28020.692317 0.862314 27437.713895
14 24 0.850405 27877.479166 0.862779 27397.306397
15 25 0.848779 27963.183735 0.861692 27491.718861

Let's determine the best features and score RFE found.

In [64]:
best_features = results_scores.iloc[np.argmax(results_scores['mean_val_score'])]['best_features']
num_of_best_features = results_scores.iloc[np.argmax(results_scores['mean_val_score'])]['num_of_features']
best_score = results_scores['mean_val_score'].max()

X_best_features = X.loc[:, best_features]

print(f'There are {num_of_best_features} features that gives {best_score} score value.')
print('So our data now looks like:')
display(X_best_features)
There are 22 features that gives 0.8512427611044828 score value.
So our data now looks like:
MSZoning LotFrontage LotConfig Exterior1st Exterior2nd Foundation BsmtUnfSF GrLivArea GarageType SaleType SaleCondition OverallQual OverallCond GarageCars GarageArea_mul_cars TotalSF TotalPorchSF YearLstCnst Has2ndFloor HasGarage HasFireplace TotalQual
0 RL 65.0 Inside VinylSd VinylSd PConc 150.0 1710 Attchd WD Normal 6 4 2 1096.0 2416.0 61 104 1 1 0 30
1 RL 80.0 FR2 MetalSd MetalSd CBlock 284.0 1262 Attchd WD Normal 5 7 2 920.0 2240.0 298 77 0 1 1 31
2 RL 68.0 Inside VinylSd VinylSd PConc 434.0 1786 Attchd WD Normal 6 4 2 1216.0 2272.0 42 102 1 1 1 30
3 RL 60.0 Corner Wd Sdng Wd Shng BrkTil 540.0 1717 Detchd WD Abnorml 6 4 3 1926.0 1933.0 307 20 1 1 1 32
4 RL 84.0 FR2 VinylSd VinylSd PConc 490.0 2198 Attchd WD Normal 7 4 3 2508.0 2853.0 276 101 1 1 1 31
... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ...
1444 RL 62.0 Inside VinylSd VinylSd PConc 953.0 1647 Attchd WD Normal 5 4 2 920.0 1647.0 40 100 1 1 1 31
1445 RL 85.0 Inside Plywood Plywood CBlock 589.0 2073 Attchd WD Normal 5 5 2 1000.0 3026.0 349 79 0 1 1 35
1446 RL 66.0 Inside CemntBd CmentBd Stone 877.0 2340 Attchd WD Normal 6 8 1 252.0 2615.0 60 56 1 1 1 25
1447 RL 68.0 Inside MetalSd MetalSd CBlock 0.0 1078 Attchd WD Normal 4 5 1 240.0 2156.0 478 51 0 1 0 33
1448 RL 75.0 Inside HdBoard HdBoard CBlock 136.0 1256 Attchd WD Normal 4 5 1 276.0 2376.0 804 66 0 1 0 33

1449 rows × 22 columns

Hyper-parameter Analysis

So let's try to change some of the hyper-parameters of our best model (which is SGRRegressor).

Learning Rate

In [65]:
# %%time
def learning_rate_selection(X, t):
  min_learning_rate = 0.0001
  max_learning_rate = 0.1
  delta = 0.0001

  X_encoded = encode(X)

  results_df = pd.DataFrame(columns=['learning_rate', 'mean_val_score', 'mean_val_loss', 'mean_train_score', 'mean_train_loss'])

  pbar = tqdm(np.arange(min_learning_rate, max_learning_rate+delta, delta), total=max_learning_rate // min_learning_rate)
  for i in pbar:
    pbar.set_description(f'Calculating for learning rate {i}')
    model = SGDRegressor(random_state=1, eta0=i, learning_rate="constant").fit(X_encoded, t)

    mean_val_score, mean_val_loss, mean_train_score, mean_train_loss, fig_score, fig_loss = get_cv_score_and_loss(X_encoded, t, 'SGDRegression', model, k=10, use_pbar=False)
    if mean_val_score < 0:
      break
    results_df.loc[len(results_df)] = [i, mean_val_score, mean_val_loss, mean_train_score, mean_train_loss]

  fig = go.Figure()
  fig.add_trace(go.Scatter(x=results_df['learning_rate'], y=results_df['mean_val_score']))
  fig.update_xaxes(title_text='Learning Rate')
  fig.update_yaxes(title_text='Cross validation score (no. of correct classifications)')
  fig.show()

  return results_df


results_learning_rate = learning_rate_selection(X_best_features, t)

The algorithm founds that in learning rate of 0.0044 we reach a negative score, and probably we're down in the score, so we stopped it.

In [66]:
display(results_learning_rate)
learning_rate mean_val_score mean_val_loss mean_train_score mean_train_loss
0 0.0001 0.813720 31286.035400 0.828234 30692.487868
1 0.0002 0.817657 30840.578170 0.833359 30229.063909
2 0.0003 0.812259 31173.971257 0.830484 30463.207477
3 0.0004 0.823965 30358.095508 0.835950 29988.700039
4 0.0005 0.824851 30268.038173 0.834913 30085.214735
5 0.0006 0.825055 30228.653439 0.836442 29939.827272
6 0.0007 0.824558 30236.962189 0.835930 29978.846060
7 0.0008 0.823482 30279.905187 0.835001 30050.110857
8 0.0009 0.821911 30350.031156 0.833740 30144.532696
9 0.0010 0.822155 30183.553418 0.836103 29914.645831
10 0.0011 0.817803 30369.888196 0.832409 30223.628076
11 0.0012 0.828278 29706.620172 0.838827 29703.400884
12 0.0013 0.828214 29766.873540 0.839950 29586.540535
13 0.0014 0.826166 29917.829940 0.837061 29843.507414
14 0.0015 0.824743 30001.429673 0.835682 29950.921955
15 0.0016 0.808390 31194.216718 0.816611 31415.209172
16 0.0017 0.786440 32440.194150 0.798700 32838.471132
17 0.0018 0.805558 31334.545273 0.812477 31691.170018
18 0.0019 0.818546 30414.210056 0.825318 30777.225811
19 0.0020 0.816362 30552.550767 0.823135 30941.880648
20 0.0021 0.814920 30990.591640 0.820389 31265.726477
21 0.0022 0.782068 33687.031644 0.781975 33811.722281
22 0.0023 0.784726 33314.019182 0.785655 33477.294888
23 0.0024 0.785314 32572.549528 0.803282 32543.737839
24 0.0025 0.771843 33630.894143 0.791823 33461.813368
25 0.0026 0.786833 32867.244183 0.797784 32938.974293
26 0.0027 0.781436 33258.536687 0.792034 33361.142028
27 0.0028 0.775533 33684.842489 0.785693 33819.927952
28 0.0029 0.799005 32612.091270 0.804307 32538.531528
29 0.0030 0.794137 33023.399130 0.798491 32971.261921
30 0.0031 0.788817 33466.993291 0.792089 33437.734130
31 0.0032 0.783044 33941.986012 0.785093 33936.758978
32 0.0033 0.761371 35605.843225 0.756661 35660.746229
33 0.0034 0.720245 37776.061650 0.720706 38099.031171
34 0.0035 0.638053 42194.719246 0.654774 42538.811266
35 0.0036 0.646523 41085.713443 0.671641 41459.963631
36 0.0037 0.653708 40073.156352 0.683058 40490.493075
37 0.0038 0.643066 40333.446079 0.670700 41045.173947
38 0.0039 0.588176 43562.830644 0.610785 44484.546126
39 0.0040 0.555313 44920.876478 0.581316 45881.227963
40 0.0041 0.510933 46633.701993 0.541878 47633.357289
41 0.0042 0.290966 56065.200082 0.351786 56204.703421
42 0.0043 0.306009 54700.524519 0.372171 54277.006505
43 0.0044 0.089284 61339.219756 0.181032 60871.441403

Let's determine the best learning rate and score.

In [67]:
best_learning_rate = results_learning_rate.iloc[np.argmax(results_learning_rate['mean_val_score'])]['learning_rate']
best_score_learning_rate = results_learning_rate['mean_val_score'].max()

print(f'The best learning rate is {best_learning_rate} and gained {best_score_learning_rate} of score.')
The best learning rate is 0.0012000000000000001 and gained 0.8282776298789323 of score.

Max Iterations

Because until now every time we run the model and did not pass the maximum number of iterations (we would get an warning then), we can conclude that there is no effect on the result on this hyper-parameter. So we'll keep use the default max iterations which is 1000.

Regularization Term

In [68]:
%%time
def alpha_selection(X, t):
  min_alpha = 0.001
  max_alpha = 0.1
  delta = 0.001

  X_encoded = encode(X)

  results_df = pd.DataFrame(columns=['alpha', 'mean_val_score', 'mean_val_loss', 'mean_train_score', 'mean_train_loss'])

  pbar = tqdm(np.arange(min_alpha, max_alpha+delta, delta), total=max_alpha // min_alpha)
  for i in pbar:
    pbar.set_description(f'Calculating for alpha {i}')
    model = SGDRegressor(random_state=1, eta0=best_learning_rate, learning_rate='constant', alpha=i).fit(X_encoded, t)
    mean_val_score, mean_val_loss, mean_train_score, mean_train_loss, fig_score, fig_loss = get_cv_score_and_loss(X_encoded, t, 'SGDRegression', model, k=10, use_pbar=False)
    if mean_val_score < 0:
      break
    results_df.loc[len(results_df)] = [i, mean_val_score, mean_val_loss, mean_train_score, mean_train_loss]

  fig = go.Figure()
  fig.add_trace(go.Scatter(x=results_df['alpha'], y=results_df['mean_val_score']))
  fig.update_xaxes(title_text='Alphas')
  fig.update_yaxes(title_text='Cross validation score (no. of correct classifications)')
  fig.show()

  return results_df


results_alpha = alpha_selection(X_best_features, t)
CPU times: user 58.1 s, sys: 38.6 s, total: 1min 36s
Wall time: 54.3 s
In [69]:
display(results_alpha)
alpha mean_val_score mean_val_loss mean_train_score mean_train_loss
0 0.001 0.828368 29699.189134 0.838905 29696.192919
1 0.002 0.828462 29691.485817 0.838986 29688.755010
2 0.003 0.828549 29684.327987 0.839061 29681.881451
3 0.004 0.830863 29535.219886 0.841677 29439.459762
4 0.005 0.830904 29531.154496 0.841715 29435.842030
... ... ... ... ... ...
95 0.096 0.837243 29200.872169 0.844650 29194.120603
96 0.097 0.837220 29203.465424 0.844615 29197.443174
97 0.098 0.837197 29206.071701 0.844580 29200.776814
98 0.099 0.837174 29208.690922 0.844545 29204.121419
99 0.100 0.837150 29211.323009 0.844509 29207.476889

100 rows × 5 columns

In [70]:
best_alpha = results_alpha.iloc[np.argmax(results_alpha['mean_val_score'])]['alpha']
best_score_alpha = results_alpha['mean_val_score'].max()

print(f'The best alpha is {best_alpha} and gained {best_score_alpha} of score.')
The best alpha is 0.09 and gained 0.8373791832261418 of score.

Prediction

Let's take a look on our final model.

In [71]:
numerical_cols, categorical_cols = determine_dtypes(X_best_features)

final_model = SGDRegressor(random_state=1, eta0=best_learning_rate, learning_rate='constant', alpha=best_alpha)

preprocessor = ColumnTransformer([
                                  ("encoding", OrdinalEncoder(), categorical_cols),
                                  ("standard", StandardScaler(), numerical_cols)
])
pipe = make_pipeline(preprocessor, final_model)
set_config(display='diagram')
display(pipe)
Pipeline(steps=[('columntransformer',
                 ColumnTransformer(transformers=[('encoding', OrdinalEncoder(),
                                                  Index(['MSZoning', 'LotConfig', 'Exterior1st', 'Exterior2nd', 'Foundation',
       'GarageType', 'SaleType', 'SaleCondition', 'OverallCond'],
      dtype='object')),
                                                 ('standard', StandardScaler(),
                                                  Index(['LotFrontage', 'BsmtUnfSF', 'GrLivArea', 'OverallQual', 'GarageCars',
       'GarageArea_mul_cars', 'TotalSF', 'TotalPorchSF', 'YearLstCnst',
       'Has2ndFloor', 'HasGarage', 'HasFireplace', 'TotalQual'],
      dtype='object'))])),
                ('sgdregressor',
                 SGDRegressor(alpha=0.09, eta0=0.0012000000000000001,
                              learning_rate='constant', random_state=1))])
ColumnTransformer(transformers=[('encoding', OrdinalEncoder(),
                                 Index(['MSZoning', 'LotConfig', 'Exterior1st', 'Exterior2nd', 'Foundation',
       'GarageType', 'SaleType', 'SaleCondition', 'OverallCond'],
      dtype='object')),
                                ('standard', StandardScaler(),
                                 Index(['LotFrontage', 'BsmtUnfSF', 'GrLivArea', 'OverallQual', 'GarageCars',
       'GarageArea_mul_cars', 'TotalSF', 'TotalPorchSF', 'YearLstCnst',
       'Has2ndFloor', 'HasGarage', 'HasFireplace', 'TotalQual'],
      dtype='object'))])
Index(['MSZoning', 'LotConfig', 'Exterior1st', 'Exterior2nd', 'Foundation',
       'GarageType', 'SaleType', 'SaleCondition', 'OverallCond'],
      dtype='object')
OrdinalEncoder()
Index(['LotFrontage', 'BsmtUnfSF', 'GrLivArea', 'OverallQual', 'GarageCars',
       'GarageArea_mul_cars', 'TotalSF', 'TotalPorchSF', 'YearLstCnst',
       'Has2ndFloor', 'HasGarage', 'HasFireplace', 'TotalQual'],
      dtype='object')
StandardScaler()
SGDRegressor(alpha=0.09, eta0=0.0012000000000000001, learning_rate='constant',
             random_state=1)
In [72]:
pipe.fit(X_best_features, t)
house_df_test_best_features = house_df_test_not_null.loc[:, best_features]
preds = pipe.predict(house_df_test_best_features)

submission = pd.DataFrame({'Id': id_test, 'SalePrice': preds})
submission.to_csv('my_submision.csv', index=False)

Summary

So in this copatition we were able to predict house prices in Ames, Iowa. We dealt with a lot of different features, some are relevant and somne are not, we researched the data and saw, we also applied common sense what can affect the price and what can not - and accordingly we droped features.
This was the big problem in my opinion - to know which features can best predict the prices.

We have seen that using the Linear Regression model gives very poor results on this data so we did not even try to change its parameters. In addition, in the Elastic Net model, we received a warning that we had reached the maximum number of iterations (by deafult max_iter = 1000) - so we did not use it either.

Finally we choosed SGD Regressor because it got the highest score value, and we changed its parameters accordingly.

References

In [ ]:
# convert to html file
%%shell
jupyter nbconvert --to html '/content/HW2_ML_Nisan_Dalva.ipynb'
